Vibration & Shock Resistance

• Dimensions: ≤ 103 × 104 × 40 mm

• Weight: ≤ 350 g

• Ambient Temperature: –40 ~ +80 ℃

• Vibration Resistance: 10‑500 Hz, PSD = 0.005 g²/Hz, Peak Acceleration ≤ 10 g

• Shock Resistance: 20 g @ 11 ms

• Average Power Consumption: ≤ 35 W

• Supply Voltage: 12 ~ 360 VDC

Input Video Specifications

• Video Formats: Supports SDI, HDMI, H.264, H.265

• Video Resolutions: Supports 1920 × 1080, 1280 × 720, 640 × 480

• Video Frame Rates: Supports 30‑60 FPS

Interfaces

• Power Input: 12‑36 VDC

• Communication: 1× Serial Port (RS422/RS232/TTL selectable)

• Video Input: 2× HD/3G‑SDI, 1× HDMI

• Video Output: 2× HD/3G‑SDI, 1× HDMI

• Network: 2× Gigabit Ethernet Ports
